2650 Supercharged LSX 376-B15 Crate Engine w/ Wegner 2-tone LSA Drive

$28,999.00
$28,999.00


LSX 376-B15 Supercharged 2650 Crate Engine

DO NOT USE THIS CHECKOUT!

PAYMENT VIA WIRE TRANSFER or Cash Pickup ONLY. CONTACT DIRECTLY TO MAKE WIRING ARRANGMENTS AT 517-315-8940.

The LSX376-B15 is a versatile and robust engine, perfect for those looking to build a high-performance vehicle with the capability to handle significant boost levels. Its combination of durable components and high-performance design makes it a popular choice among enthusiasts.

Includes:

  • Harrop 2650i Supercharger
  • Wegner Gen 1 or 2 Billet Black Supercharger Lid Choice
  • Bosch Flow Matched 1440cc @ 43.5psi USCAR EV6 Fuel Injectors
  • Billet Black Harrop Fuel Rails
  • Wegner 2-tone LSA Drive w/ 370amp Upgraded Alternator
  • ATI Balancer w/ 18% Overdrive Ring
  • 70mm Harrop Upper Pulley
  • Belts Included
  • Snout Plugs
  • Lower Harrop Thermal Gaskets

Technical Specs:

  • Engine Type: LSX-Series Gen IV Small-Block V-8

  • Displacement: 376 cubic inches (6.2 liters)

  • Bore x Stroke: 4.065 x 3.622 inches (103.25 x 92 mm)

  • Block: LSX cast-iron with 6-bolt, cross-bolted main caps

  • Crankshaft: Forged steel

  • Connecting Rods: Forged powdered metal

  • Pistons: Forged aluminum

  • Camshaft Type: Hydraulic roller

  • Valve Lift: 0.560 inches intake / 0.555 inches exhaust

  • Cylinder Heads: LSX-LS3 rectangular port with 6-bolt attachment

  • Compression Ratio: 9.0:1

  • Maximum Recommended RPM: 6,600

  • Recommended Fuel: Regular pump

  • Boost Support: Up to 15 pounds of boost

Prices:

Freight shipping $450-650
