Atomizer ST FURY 575 PPH 6100cc/min @90psi Fuel Injector – Low Impedance

Atomizer ST FURY 575 PPH Fuel Injector – Ultra High-Flow Motorsport Injector

The Atomizer ST FURY 575 PPH is a low-impedance, ultra-high-flow fuel injector designed for extreme horsepower applications. Rated at 575 pounds per hour at 90 psi (approximately 6,100cc/min), this injector is engineered for use with methanol, ethanol, gasoline, and nitromethane in high-boost or large-displacement race engines.

Built with a standard-length billet aluminum body, the ST FURY 575 features a Jetronic/Minitimer (Bosch EV1) connector, dual Viton O-rings, and a 14mm lower O-ring diameter for compatibility with most racing intake manifolds and fuel rails. Its internal components are optimized for fast response, clean idle, and consistent atomization even at extreme flow demands.

Each unit is individually flow-tested, serialized, and matched to ensure uniform performance across multi-cylinder setups. The injector is also 100% rebuildable, allowing for long-term maintenance and reliability in competitive environments.

Specifications:

• Flow Rate: 575 lb/hr @ 90 psi (~6100cc/min)

• Impedance: Low impedance (~1.6 Ohm) – requires peak-and-hold drivers

• Body Style: Standard length, billet aluminum

• Connector: Jetronic/Minitimer (Bosch EV1)

• Seals: Dual Viton O-rings (14mm)

• Length: 60mm overall

• Compatibility: Methanol, Ethanol, Gasoline, Nitromethane

• Serviceability: 100% rebuildable

• Testing: Individually flow-tested, serialized, and matched
