WAK053 GM LSA 1.9L

This LSA drive kit was engineered for high performance street use with key features such as:

• Supercharger runs on dedicated 8 rib belt for max overdrive
• Runs SC on OE LSA alignment so you can run stock damper and SC pulley for stock boost
• Max pulley belt wrap for NO slip, extra idler pulley to give power steering complete wrap
• Rigid design eliminates component flex
• Internal fan alternator cools better while also allowing for more RPM
• High quality & heavy duty components
• CAD designed & CNC machined brackets & pulleys
• Drive will support SC pulleys for up to 875 HP
• Runs OE water pump
• Drive will work with 90mm & 102mm DBW Throttle Body

Crank Pully

Utilizes OEM LSA crank pulley

Options:
ATI damper crank pulley
Supercharger pulley diameter: OEM, 5%, 11%, 15%, or 18.5% overdrive

Power Steering Pump

GM Type 2, by PSC Motorsports

• -6 and -10 AN fittings for Remote Res.

Alternator

170 Amp single wire or GM 2 pin with internal fan
Optional: 225 Amp upgrade

Air Conditioning

Sanden SD7 AC Compressor

Note: (This product may subject to delays due to manufacturing and shipping)

All accessory drives are built to order - please allow 4-6 weeks for delivery
